8 variable PROFIBUS PA indicator, Intrinsically safe, panel mounting – BA448CF-P
Features:
Intrinsic safety certification.
FISCO compliant
Large 5 digit 20mm high display+ 31 segment bargraph.
Displays up to 8 variables
PROFIBUS PA protocol
Configurable as Node or Listener
Bus powered
Fieldbus indicators and displays summaryProduct dimensionsPROFIBUS PA FAQ’S
| Approvals | ATEX, CCOE, FM, IECEx, UKEX |
|---|---|
| Communication protocol | PROFIBUS PA |
| Display | Large 5 digit 20mm high display+ 31 segment bargraph |
| Protection class | IP20, IP66 |
| Brand | Beka |
| Mounting | Panel |
| Options Available | CCOE Dust |
Product details
This cost effective BA448CF-P PROFIBUS PA indicator displays up to eight fieldbus process variables on a bold five digit display and a 31 segment analogue bargraph. If required the indicator address may be entered via the front panel push buttons eliminating the need for a PROFIBUS configurator.
This panel mounting model has an IP66 front panel with a gasket to seal the joint between the instrument and the panel.
The fieldbus indicator has ATEX, FM, cFM and IECEx intrinsically safe certification and complies with the Fieldbus Intrinsically Safe Concept FISCO. It also has Ex ia and Ex ic entity input safety parameters allowing connection to most intrinsically safe fieldbus segments.
