Absolute Rotary Encoder – Multiturn REM-103S6S-3C13S12M-H1181
Absolute Rotary Encoder – Multiturn
| Ambient temperature max. (°C) | 85 |
|---|---|
| Ambient temperature min. (°C) | -40 |
| Communication protocol | SSi |
| Connector type | M12 × 1 |
| Design | Solid shaft |
| Electrical output | Connector |
| Encoder line | Industrial-Line |
| Flange diameter (mm) | 58 |
| Flange type | Synchro flange |
| Housing material | Die-cast zinc |
| Measuring principle | Optical |
| Output type | Absolute multiturn |
| Protection class | IP67 |
| Protection class shaft | IP67 |
| Shaft diameter D (mm) | 6 mm |
| Shaft Type | Solid shaft |
| Technology | Optical |
