Banner – BR-M12F12R9-2
Receptacle 12-pin Female
12×24 PVC 2 m Length
Rear Mount PG9 w/ Locknut
| Connector 1 Thread/Snap | Threaded |
|---|---|
| Cordset Length (m) | 2.0 |
| Coupling Nut Material | Nickel Plated Brass |
| Number of Conductors | 12.0 |
| Wire AWG | 24 |
| Connector 1 Key Code | A |
| Connector 1 Type | M12 |
| Connector 2 Type | Flying Leads |
| Connector B | Female |
| Current (A) | 1.5 |
| Indication | No |
| Number of Ends | Single Ended |
| Oil/Grease Resistant | No |
| Operating voltage | 30 V ac/dc |
| Protection class shaft | IP67 |
| Maximum Temp. (Celsius) | 70.0 |
| Number of pins.1 | 12.0 |
| Minimum Temp. (Celsius) | -40.0 |
Description
Receptacle 12-pin Female
12×24 PVC 2 m Length
Rear Mount PG9 w/ Locknut
