Banner – BR-M23M19F13-2
Receptacle 19-pin Male
3×18+16×22 AWG PVC 2 m Length
Front Mount with PG 13.5 Threads
| AWG | 22, 18 |
|---|---|
| Cordset Length (m) | 2.0 |
| Coupling Nut Material | Nickel Plated Brass |
| Shield/No Shield | No Shield |
| Connector 1 Type | M23 |
| Connector B | Male |
| Current (A) | 4.0 (22 AWG), 8.0 (18 AWG) |
| Item Status | RELEASED |
| Number of Ends | Single Ended |
| Operating voltage | 150 V ac/dc |
| Maximum Temp. (Celsius) | 80.0 |
| Number of pins.1 | 19.0 |
| Minimum Temp. (Celsius) | -15.0 |
Description
Receptacle 19-pin Male
3×18+16×22 AWG PVC 2 m Length
Front Mount with PG 13.5 Threads
