Banner – iPW-BD120-2
Accessories: Power Supply
Input Supply Voltage: 88-132 V ac/176-264 V ac; Output: 5 V dc; 2-10 A/24 V dc; 0.4-4 A; 120 W
CE Approval
| Item Status | RELEASED – PHASE OUT |
|---|---|
| Power Good Output | DC |
| Max Op. Temperature (C) | 50.0 |
| Output Voltage | 5 V and 24 V dc |
| Rise Time (ms) | 50.0 |
| Power(Watt) | 120.0 |
| Storage Temperature | -40 to 85 |
| Output Current (A) | 10/4 |
| Effectiveness (%) | 80 |
| Options Available | cFM Certification |
Description
Accessories: Power Supply
Input Supply Voltage: 88-132 V ac/176-264 V ac; Output: 5 V dc; 2-10 A/24 V dc; 0.4-4 A; 120 W
CE Approval
