Banner – K50FLRGWPQ
K50 Series EZ-LIGHT: 3-Color General Purpose Flat Pack Indicator
Voltage: 18-30 V dc; Environmental Rating: IP67; IP69K
Input: PNP; Colors: Red Green White
4-pin M12 Integral QD
| Light type | No |
|---|---|
| Mounting | No Thread |
| Number of colors/segments | 3 |
| Number of Conductors | 4.0 |
| Operating voltage | 18-30 V dc |
| Port | M12 |
| Power Good Output | DC |
| Protection class shaft | IP67, IP69K |
| Radio interface | No |
| Receptacle housing material B | Polycarbonate |
| Touchscreen | No |
| Item Status | RELEASED |
| Housing Style | Flat Pack Dome |
| Connection | Integral QD |
| Min Op. Temperature (C) | -40.0 |
| Feature: Audible | No |
| Indication | Yes |
| High Temperature (up to 100 C) | 50.0 |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 76.0 x 44.6 |
| Color Technology | Standard LED |
| Environmental Rating | IP67; IP69K |
| Product Size (mm) | 50 |
| Eye Shield | No |
| USB | No |
| Non-Illuminated | No |
| PFM Input | No |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Color Option 1 | Red |
| Primary Window Material | Polycarbonate Diffused |
| IO Link | No |
| Max Current Color (mA) | 40.0 |
| Animation Option 1 | Solid On |
| Multi-Color Device | Single Color On |
| Primary Housing Color | Black |
| Input Type | PNP |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Max Input Response Time (ms) | 1.0 |
| Modbus RTU | No |
| Color Option 2 | Green |
| Pro-Editor Compatible (Discrete) | No |
| Color Option 3 | White |
| Programmable | No |
| Lighting Device Type | Indicator |
| Discrete | Yes |
| Feature | Encapsulated, Quick Disconnect, Washdown Rated |
Description
K50 Series EZ-LIGHT: 3-Color General Purpose Flat Pack Indicator
Voltage: 18-30 V dc; Environmental Rating: IP67; IP69K
Input: PNP; Colors: Red Green White
4-pin M12 Integral QD
