Banner – SG-TL70P-RGBC
TL70 Pro Light Module; Use with TL70 Pro Base
Voltage: 12-30 V dc; Environmental Rating: IP65
14-color RGB; Gray Housing
| Color Technology | RGB Configurable |
|---|---|
| Dimming Option | Programmable |
| Feature: Audible | No |
| Primary Housing Color | Gray |
| Primary Window Material | Polycarbonate Diffused |
| Animation Option 1 | IO-Link Controlled |
| Color Option 1 | RGB |
| Environmental Rating | IP65 |
| Eye Shield | No |
| Housing Style | Segment – Light |
| Indication | Yes |
| IO Link | Yes |
| Item Status | RELEASED |
| Light type | No |
| Lighting Device Type | Light Module |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Modbus RTU | No |
| Mounting | No Thread |
| Multi-Color Device | Single Color On |
| Non-Illuminated | No |
| Number of colors/segments | 14 |
| PFM Input | No |
| Physical Dimensions (LxWxH or DxH mm) | 70.0 x 50.0 |
| Power Good Output | DC |
| PROFINET | Yes |
| Programmable | Yes |
| Protection class shaft | IP65 |
| Radio interface | No |
| Receptacle housing material B | Polycarbonate |
| Touchscreen | No |
| Number of Tower Light Segments | 1.0 |
| USB | No |
| Min Op. Temperature (C) | -40.0 |
| NEMA / UL Type Rating | NEMA 4X |
| High Temperature (up to 100 C) | 50.0 |
| Product Size (mm) | 70 |
| Storage Temp (C) | -40 to 70 |
| Options Available | Modbus |
Description
TL70 Pro Light Module; Use with TL70 Pro Base
Voltage: 12-30 V dc; Environmental Rating: IP65
14-color RGB; Gray Housing
