Bus Cable for CAN (DeviceNet, CANopen) RSC WKC 5711-10M
Bus Cable for CAN (DeviceNet, CANopen)
| Application | Data |
|---|---|
| Approvals | CSA, UL |
| Cable color | Gray |
| Cable length (m) | 10 |
| Cable quality | PVC |
| Connector A | A-coded, M12×1, Male, Straight |
| Connector B | A-coded, Angled, Female, M12×1 |
| Coupling nut/screw material A | Brass |
| Coupling nut/screw material B | Brass |
| Current (A) | 4 |
| Design | Extension Cable |
| Network protocol | CANopen, DeviceNet |
| Number of Conductors | 2 |
| Number of pins | 5 |
| Special features | Shielded |
| Voltage output | 250 |
| Core cross section mm? | 0.52 |
