Detection Arrays and Wide Beam Sensors – Banner – EA5K300PIXMODQ
Kit EA5E300Q, EA5R300PIXMODQ
| Analog Output | Current (4-20 mA) |
|---|---|
| Array Length (mm) | 300.0 |
| Beam Spacing | 5 mm |
| Discrete Output | PNP |
| Emitter/Receiver Range (m) | 0.4 – 4 |
| Housing Length (mm) | 379.0 |
| Low Contrast | No |
| Max Relative Humidity | 95% |
| Min Temp (C) | -40.0 |
| Minimum Object Sensitivity (mm) | 5-10 |
| Short Range | No |
| Connection technology signal | Emitter/Receiver Pair |
| Device type | Kit |
| DeviceNet | No |
| IO Link | No |
| Item Status | RELEASED |
| Modbus RTU | Yes |
| Number of beams | 60.0 |
| Operating voltage | 12-30 V dc |
| Receptacle housing material B | Aluminum |
| RS-232 | No |
| RS-485 | Yes |
Description
Kit EA5E300Q, EA5R300PIXMODQ
