Field-Wireable Connector BKV8240-0/9
Field-Wireable Connector
| Application | Data |
|---|---|
| Connection technology signal | M12 |
| Connector A | A-coded, Angled, Female, M12×1 |
| Coupling nut/screw material A | Stainless Steel |
| Cross-sectional connection max. (mm²) | 0.75 mm² |
| Device type | Field-wireable connector |
| Network protocol | FOUNDATION fieldbus, PROFIBUS-PA |
| Number of pins | 4 |
| Plug body | Plastic |
| Screw-in thread | PG9 |
| Voltage output | 250 |
