Field-Wireable Connector FW-ERSSM0426-FD-P-0408
Field-Wireable Connector
| Application | Data |
|---|---|
| Approvals | cULus |
| Connection mode | Push-in connection |
| Connector A | D-coded, M12×1, Male, Straight |
| Coupling nut/screw material A | Die-cast Zinc |
| Cross-sectional connection max. (mm²) | 0.75 mm² |
| Device type | Field-wireable connector |
| Network protocol | Ethernet |
| Number of pins | 4 |
| Plug body | Die-cast Zinc |
