Field-Wireable Connector FW-RRSSP0822-IE-I-0510
Field-Wireable Connector
| Application | Data |
|---|---|
| Connection mode | Insulation displacement terminal |
| Connector A | Male, RJ45, Straight |
| Cross-sectional connection max. (mm²) | 0.34 mm² |
| Current (A) | 1 |
| Device type | Field-wireable connector |
| Network protocol | Ethernet, Ethernet CAT6A |
| Number of pins | 8 |
| Plug body | Die-cast Zinc |
| Voltage output | 50 |
