Flow Monitoring FCIC-G1/4A4P-AP8-H1141/0.5
Flow Monitoring
| Ambient temperature max. (°C) | 60 |
|---|---|
| Ambient temperature min. (°C) | |
| Application area | Standard |
| Approvals | cULus |
| Connector type | M12 × 1 |
| Design | Inline |
| Detection type | Calorimetric |
| Electrical output | Connector |
| Function | Flow monitoring |
| Housing material | Plastic |
| Housing quality | PBT-GF30 |
| Media temperature max. (°C) | 60 |
| Media temperature min. (°C) | |
| Medium | liquids |
| Mounting conditions | Inline sensor |
| Operating voltage | DC |
| Output function | PNP |
| Process connection | G 1/4” |
| Protection class | IP67 |
| Switching element function | NO contact |
