Incremental Encoder REI-04Q6S-2H200-H1181
Incremental Encoder
| Ambient temperature max. (°C) | 85 |
|---|---|
| Ambient temperature min. (°C) | -20 |
| Connector type | M12 × 1 |
| Design | Solid shaft |
| Electrical output | Connector |
| Encoder line | Industrial-Line |
| Flange diameter (mm) | 36.5 |
| Flange type | Synchro flange |
| Housing material | Aluminum chromated |
| Measuring principle | Optical |
| Output function | Push-Pull/HTL |
| Output type | Incremental |
| Protection class | IP65 |
| Protection class shaft | IP50 |
| Resolution incremental (ppr) | 200 |
| Shaft diameter D (mm) | 6 mm |
| Shaft Type | Solid shaft |
| Special features | Compact |
| Technology | Optical |
