Inductive Sensor NI20U-TS12-AN6X2-V1131
Inductive Sensor
| Ambient temperature max. (°C) | 70 |
|---|---|
| Ambient temperature min. (°C) | -25 |
| Connector type | M8 x 1 |
| Construction size | 80 x 17 x 12 mm |
| Design | Rectangular |
| Dimensions | 80 mm x 17 mm x 12 mm |
| Electrical output | Connector |
| Housing material | Plastic |
| Housing quality | PBT-GF30-V0 |
| Mounting conditions | Non-flush |
| Operating voltage | DC |
| Output function | NPN |
| Protection class | IP68 |
| Rated switching distance (mm) | 20 |
| Special features | Factor 1, Resistant to magnetic fields, Sn +, uprox+ |
| Switching element function | NO contact |
| Switching frequency (kHz) | 0.008 |
