Modbus RTU display, General purpose, panel mounting – BA688C
Features:
High contrast 86.5mm x 45mm display with backlight
Modbus, BEKA & Legacy protocols
Operator push buttons & two solid state outputs
RS232 & RS485 ports
Video: Modbus RTU displays11 Standard displays with up to 8 variablesModbus RTU displays FAQ’S
Product details:
eleven standard screen formats
ScreenWriter software
| Communication protocol | Modbus, BEKA & Legacy |
|---|---|
| Display | High contrast 86.5mm x 45mmwith backlight, up to 8 variables |
| Protection class | IP20, IP66 |
| Brand | Beka |
| Mounting | Panel |
| Options Available | Push Buttons |
Product details
This BA688C displays text and simple graphics in a process area. Incorporating a high contrast backlit display, push buttons and two solid state outputs, this low cost operator interface is ideal for simple process control applications.
The text display, which has RS232 and RS485 ports, supports Modbus, BEKA and legacy protocols and includes eleven standard screen formats which display up to eight variables on each screen, some with bargraphs. If custom display formats are required, these can be constructed using the free BEKA ScreenWriter software.
A powerful Pattern Matching facility is resident in the Modbus RTU display which enables the capture and display of data contained in proprietary ASCII serial strings.
