Photoelectric Sensor QMH26VPAF200-5M
Photoelectric Sensor
| Ambient temperature max. (°C) | 70 |
|---|---|
| Ambient temperature min. (°C) | -30 |
| Cable length (m) | 5 |
| Design | Rectangular |
| Dimensions | 20.3 mm x 14 mm x 32.6 mm |
| Electrical output | Cable |
| Function | Proximity switch |
| Housing material | Metal |
| Housing quality | Stainless steel |
| Light type | Red |
| Max. range (mm) | 200 |
| Operating mode | adjustable, Background suppression |
| Output function | PNP |
| Protection class | IP69 |
| Setting option | Screw Adjustment |
| Special features | Chemical-resistant, Resistant to chemicals, Wash down |
| Switching element function | Complementary contact |
| Switching frequency (kHz) | 2 |
| Wavelength (nm) | 660 |
