Pressure Transmitter PT700R-2010-I2-H1143/X
Pressure Transmitter
| Ambient temperature max. (°C) | 85 |
|---|---|
| Ambient temperature min. (°C) | -30 |
| Connector type | M12 × 1 |
| Design | Without display |
| Electrical connection | Current output (2-wire) |
| Electrical output | Connector |
| Housing material | Stainless-steel/Plastic |
| Housing quality | 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 |
| Material pressure transducer | Stainless steel 1.4435 (AISI 316L) |
| Media temperature max. (°C) | 135 |
| Media temperature min. (°C) | -40 |
| Operating voltage | DC |
| Output function | Analog output current |
| Pressure range | 0…700 bar |
| Pressure type | Relative pressure |
| Process connection | R 1/4″ male thread EN 10226 |
| Protection class | IP67 |
