PROFIBUS Cable RKSW D9S/T 455-4M
PROFIBUS Cable
| Ambient temperature max. (°C) | 80 |
|---|---|
| Ambient temperature min. (°C) | -40 |
| Application | Data |
| Cable color | Violet |
| Cable length (m) | 4 |
| Cable quality | PVC |
| Connector A | B-coded, Female, M12×1, Straight |
| Current (A) | 4 |
| Design | Extension Cable |
| Network protocol | PROFIBUS-DP |
| Number of Conductors | 2 |
| Number of pins | 5 |
| Special features | Shielded |
| Voltage output | 250 |
| Connector B | Angled, D-Sub, Male |
| Core cross section mm? | 0.34 |
| Coupling nut/screw material A | Brass |
