Q45 Switches and Push Buttons – Banner – DX80N9Q45RD-QPF-0.5
Wireless Q45 Remote Device Node
Dry Contact or Namur Inputs 900 MHz
With Female M12 Pigtail
| Connection mode | Dry contact, NAMUR Proximity Sensors |
|---|---|
| Device type | Node |
| Operating voltage | 2 AA Batteries |
| Port | M12 |
| Power Good Output | Battery |
| Protection class shaft | IP67 |
| Radio interface | Yes |
| Item Status | RELEASED |
| Housing Style | Integrated Battery |
| Connection | Pigtail QD |
| NEMA / UL Type Rating | NEMA 4X |
| Input/Output | Discrete |
| Modbus RTU | No |
| RS-232 | No |
| PROFINET | No |
| EtherNet/IP | No |
| Intrinsically Safe | No |
| Min Operating Temperature (C) | -40.0 |
| RS-485 | No |
| Max Operating Temperature (C) | 70.0 |
| LCD Display | No |
| Wireless Radio Frequency | 900 MHz |
| 1-wire Serial Interface | No |
| Max Temp Operating Conditions (C) | 70.0 |
| Min Temp Operating Conditions (C) | -40.0 |
| Tree Topology | No |
| Point-to-Point Topology | Yes |
| Star Topology | Yes |
| Point-to-Multipoint Topology | Yes |
| Ships With Battery | Yes |
| Relative Humidity | 90% at 50° C |
| Number of Discrete Inputs | Yes |
| Cert | Australia/New Zealand, Canada, Korea, Thailand |
| Feature | Quick Disconnect |
Description
Wireless Q45 Remote Device Node
Dry Contact or Namur Inputs 900 MHz
With Female M12 Pigtail
