Radar Sensor K50RPF-8060-LDQ
Radar Sensor
| Ambient temperature max. (°C) | 60 |
|---|---|
| Ambient temperature min. (°C) | -40 |
| Connector type | M12 × 1 |
| Construction size | 76 x 50 x 23.1 mm |
| Design | Rectangular |
| Dimensions | 76 mm x 50 mm x 23.1 mm |
| Electrical output | Connector |
| Function | Proximity switch |
| Housing material | Plastic |
| Housing quality | PC |
| Max. range (mm) | 2500 |
| Operating mode | Time-of-Flight |
| Operating voltage | DC |
| Output function | PNP/NPN |
| Protection class | IP67 |
| Setting option | Remote Teach, Vision Software and Firmware |
| Switching element function | NO/NC programmable |
| Antenna connection | Internal, planar |
| Beam angle | 80° × 60° |
| Frequency band | F band, ISM region |
| Frequency range | 60.5 GHz |
