Rope Pull Stop Control Device – Banner – RP-LM40D-6
Heavy Duty Metal Stop Control Rope Pull
Ring Attachment, 6 m Max Range
1 NC Rope Pulled Contact
1 NC Rope Break Contact
| Attachment | Ring |
|---|---|
| Contact Quantity | 2 NC |
| Contact Rating | 6 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 124.5 x 40 x 37.5 |
| Max Cable Length (m) | 6 |
| Max Operating Temperature (C) | 80 |
| Min Operating Temperature (C) | -30 |
| Actuation | Trip |
| Device type | Rope Pull |
| EPLAN Original Sent Date | 02/25/2026 |
| EPLAN Status | Pending Publish |
| Housing Style | Limit Switch |
| Item Status | RELEASED |
| Protection class shaft | IP65 |
| Receptacle housing material A | Zinc Alloy Die-Cast |
| Receptacle housing material B | Aluminum Alloy Die-Cast |
| Voltage supply connection | Wiring Chamber |
Description
Heavy Duty Metal Stop Control Rope Pull
Ring Attachment, 6 m Max Range
1 NC Rope Pulled Contact
1 NC Rope Break Contact
