Serial Data Radios – Banner – R70SR2MQ
R70 Serial Data Radio Multihop 2.4 GHz 65 mW
Internal Antenna
RS-485
5-pin M12 Integral QD
| 1-wire Serial Interface | No |
|---|---|
| LCD Display | No |
| Max Temp Operating Conditions (C) | 50.0 |
| Min Temp Operating Conditions (C) | -40.0 |
| Output Details | Serial |
| Point-to-Multipoint Topology | Yes |
| Point-to-Point Topology | Yes |
| Relative Humidity | 90% at 50° C |
| Star Topology | Yes |
| Tree Topology | Yes |
| Wireless Radio Frequency | 2.4 GHz |
| Cert | Canada, Thailand, US |
| Connection mode | Serial |
| Device type | Multihop Data Radio |
| EPLAN Original Sent Date | 09/12/2024 |
| EPLAN Status | Published |
| EtherNet/IP | No |
| Housing Style | Base |
| Input/Output | Serial |
| Intrinsically Safe | No |
| Item Status | RELEASED |
| Modbus RTU | Yes |
| Operating voltage | 10-30 V dc |
| Power Good Output | DC |
| PROFINET | No |
| Protection class shaft | IP65 |
| Radio interface | Yes |
| RS-232 | No |
| RS-485 | Yes |
| NEMA / UL Type Rating | NEMA 4X |
Description
R70 Serial Data Radio Multihop 2.4 GHz 65 mW
Internal Antenna
RS-485
5-pin M12 Integral QD
