TL50 Pro Select Series 50 mm Programmable Tower Light – Banner – TL50PS3AQ-25X
TL50 Pro Select Tower Light; 3 Lighted Segments with Audible
Voltage: 12-30 V dc; Environ. Rating: IP65
Colors: Green Yellow Red
5-pin M12 Integral QD
Note: MOQ of QTY 25
| Audible Alarm Type | Continuous |
|---|---|
| Color Option 2 | Yellow |
| Color Technology | RGB Configurable |
| Connection | Integral QD |
| Dimming Option | Programmable |
| Feature: Audible | Yes |
| Input Type | Bimodal (PNP/NPN) |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Diffused |
| Pro-Editor Compatible (Discrete) | Yes |
| Color 1 - Wavelength/Color Temp/Coordinates | 522 nm |
| Color 2 - Wavelength/Color Temp/Coordinates | 576 nm |
| Color 3 - Wavelength/Color Temp/Coordinates | 620 nm |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Color Option 1 | Green |
| Color Option 3 | Red |
| Environmental Rating | IP65 |
| EPLAN Original Sent Date | 12/18/2023 |
| EPLAN Status | Published |
| Eye Shield | No |
| Feature | Quick Disconnect |
| Housing Style | Base Mount – Tower |
| Indication | Yes |
| IO Link | No |
| Item Status | RELEASED |
| Light type | No |
| Lumens Color 1 | 15.5 |
| Lumens Color 2 | 22.4 |
| Lumens Color 3 | 8.4 |
| Max Audible Intensity (dB at 1m) | 93.0 |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Mounting | M30 x 1.5 |
| Multi-Color Device | Simultaneous Colors On |
| Non-Illuminated | No |
| Number of colors/segments | 3 |
| Number of Conductors | 5.0 |
| Operating voltage | 12-30 V dc |
| PFM Input | Yes |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 217.2 |
| Port | M12 |
| Power Good Output | DC |
| Protection class shaft | IP65 |
| Radio interface | No |
| Receptacle housing material B | Polycarbonate |
| Switching frequency (kHz) | 3.1 |
| Touchscreen | No |
| Number of Tower Light Segments | 4.0 |
| USB | No |
| Min Op. Temperature (C) | -40.0 |
| NEMA / UL Type Rating | NEMA 4X |
| High Temperature (up to 100 C) | 50.0 |
| Product Size (mm) | 50 |
| Max Current Color (mA) | 92.0 |
| Max Input Response Time (ms) | 250.0 |
| Max Current - Audible Alarm (mA) | 45.0 |
Description
TL50 Pro Select Tower Light; 3 Lighted Segments with Audible
Voltage: 12-30 V dc; Environ. Rating: IP65
Colors: Green Yellow Red
5-pin M12 Integral QD
Note: MOQ of QTY 25
