TL70 Core Series 70mm Modular Tower Lights – Banner – B-TL70Z-5
TL70 Base Module; Supports 1-4 Modules
Voltage: 100-240 V ac; Environmental Rating: IP65
2 m (6.5 ft) Integral Cable
Black Housing
| Light type | No |
|---|---|
| Mounting | M30 x 1.5 |
| Number of Conductors | 5.0 |
| Operating voltage | 100-240 V ac |
| Power Good Output | AC |
| Protection class shaft | IP65 |
| Radio interface | No |
| Receptacle housing material B | Polycarbonate |
| Slot width (mm) | 2 |
| Touchscreen | No |
| Item Status | RELEASED |
| Housing Style | Segment – Base |
| Connection | Cable |
| Min Op. Temperature (C) | -40.0 |
| Feature: Audible | No |
| Indication | Yes |
| High Temperature (up to 100 C) | 50.0 |
| EPLAN Status | Published |
| Physical Dimensions (LxWxH or DxH mm) | 70.0 x 115.8 |
| Environmental Rating | IP65 |
| EPLAN Original Sent Date | 12/18/2025 |
| Product Size (mm) | 70 |
| Eye Shield | No |
| USB | No |
| Non-Illuminated | Yes |
| PFM Input | No |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| IO Link | No |
| Storage Temp (C) | -40 to 70 |
| Primary Housing Color | Black |
| Input Type | AC |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Max Input Response Time (ms) | 240.0 |
| Modbus RTU | No |
| Programmable | No |
| Lighting Device Type | Base Module |
Description
TL70 Base Module; Supports 1-4 Modules
Voltage: 100-240 V ac; Environmental Rating: IP65
2 m (6.5 ft) Integral Cable
Black Housing
