Ultrasonic Sensor LUS211-130-34-LI2UPN8-H1141
Ultrasonic Sensor
| Ambient temperature max. (°C) | 70 |
|---|---|
| Ambient temperature min. (°C) | -25 |
| Communication protocol | IO-Link |
| Connector type | M12 × 1 |
| Design | Smooth barrel |
| Detection type | contactless |
| Dimensions | 38 mm x 127.1 mm |
| Electrical output | Connector |
| Function | Proximity switch |
| Housing material | Stainless-steel/Plastic |
| Housing quality | 1.4404 (AISI 316L)/Grilamid TR90 UV, PA |
| Max. range (mm) | 1300 |
| Measuring principle | Ultrasonic |
| Measuring range | 1300 mm |
| Medium | Bulk goods, liquids |
| Operating mode | Time-of-Flight |
| Output function | Analog output, PNP/NPN |
| Process connection | 3/4″ NPT |
| Protection class | IP67 |
| Quality active face | Epoxy |
| Radiation direction | straight |
| Resolution | 1 cm |
| Setting option | Capacitive Sensor, IO-Link |
| Switching element function | NO/NC |
