Ultrasonic Sensor Q45UBB63BC
Ultrasonic Sensor
| Ambient temperature max. (°C) | 70 |
|---|---|
| Ambient temperature min. (°C) | -25 |
| Cable length (m) | 2 |
| Design | Rectangular |
| Dimensions | 79.4 mm x 44.5 mm x 87.6 mm |
| Electrical output | Cable |
| Function | Proximity switch |
| Housing material | Plastic |
| Housing quality | PBT |
| Max. range (mm) | 3000 |
| Operating mode | Time-of-Flight |
| Output function | PNP/NPN |
| Protection class | IP67 |
| Special features | Clear object detection, Pump function |
| Switching element function | NO contact |
| Radiation direction | straight |
