Field-Wireable Connectors for Profibus PA


These connectors allow the installer to use bulk cable to connect on site to various PA devices which have M12 and 7/8" connectors. They also allow cordsets to be shortened if required. They are available in male or female to suit various cable sizes. There are also M12 models in a right-angled design.

Designed for Profibus PA  -  All connectors are 4-Pole
Type Ident No Size Gender Cable External Diameter Terminal Capacity Design Drawing
BK4140-0/9 6914551 7/8" Female 4.0...6.0 mm 0.14…1.0 mm˛ Straight 1
BS4140-0/9 6914550 7/8" Male 6.0...8.0 mm 0.14…1.0 mm˛ Straight 2
BV4148-0/9 6914524 7/8" Female 6.0...8.0 mm 0.14…1.0 mm˛ Straight 3
BSV4148-0/9 6914523 7/8" Male 6.0...8.0 mm 0.14…1.0 mm˛ Straight 4
BV4148-0/16 6914530 7/8" Female 12…14 mm 0.14…1.0 mm˛ Straight 5
BSV4148-0/16 6914531 7/8" Male 12…14 mm 0.14…1.0 mm˛ Straight 6
BKV8140-0/9 6914538 M12 Female 4.0...8.0 mm 0.14…0.75 mm˛ Straight 7
BSV8140-0/9 6914537 M12 Male 4.0...8.0 mm 0.14…0.75 mm˛ Straight 8
BKV8240-0/9 6914540 M12 Female 4.0...8.0 mm 0.14…0.75 mm˛ Angled 9
BSV8240-0/9 6914539 M12 Male 4.0...8.0 mm 0.14…0.75 mm˛ Angled 10
BMS8141-0/9 6904702 M12 Female 4.0…9.0 mm 0.14…0.75 mm˛ Straight 11
BMSS8141-0/9 6904701 M12 Male 4.0…9.0 mm 0.14…0.75 mm˛ Straight 12



Drawings

1                                               2                                                3



BK4140-0/9                             BS4140-0/9                            BV4148-0/9





4                                                   5                                                6



BSV4148-0/9                          BV4148-0/16                       BSV4148-0/16





7                                                8                                               9

BKV8140-0/9                      BSV8140-0/9                         BKV8240-0/9





10                                        11                                      12

BSV8240-0/9                  BMS8141-0/9                   BMSS8141-0/9
