Double-Ended – Banner – BCD-RJ45 RJ45-15M
RJ45 to RJ45 Ethernet Cable
RJ45 to RJ45
15 m (49.2 ft) Length
Teal, PVC, Nickel-Plated Coupling Nut
| Cable Jacket Color | Teal |
|---|---|
| Cable Jacket Material | PVC |
| Connector 2 Gender | Male |
| Connector 2 Number of Contacts | 8.0 |
| Connector 2 Orientation | Straight |
| Cordset Length (m) | 15.0 |
| Outside Cable Diameter (mm) | 6.2 |
| Shield/No Shield | Shield – Tied to Coupling Nut |
| Coiled | No |
| Connector 1 Orientation | Straight |
| Connector 1 Type | RJ45 |
| Connector 2 Type | RJ45 |
| Connector B | Male |
| Current (A) | 0.5 |
| Indication | No |
| Item Status | RELEASED |
| Number of Ends | Double Ended |
| Oil/Grease Resistant | No |
| Operating voltage | 42 V ac/dc |
| Overmold Material and Color | PUR Black |
| Protection class shaft | IP20 |
| Maximum Temp. (Celsius) | 70.0 |
| Number of pins.1 | 8.0 |
| Minimum Temp. (Celsius) | -40.0 |
Description
RJ45 to RJ45 Ethernet Cable
RJ45 to RJ45
15 m (49.2 ft) Length
Teal, PVC, Nickel-Plated Coupling Nut
