Flush-Mount Emergency Stop Button – Banner – SSA-EB1PL2-12ED1Q8
SSA-EB1 Flush-mount Emergency Stop Push Button
Illuminated (PUSH ON) 40 mm Actuator
IP65; Contacts: 2NC/1 NO; 8-pin M12 QD
| Actuated Color | Red |
|---|---|
| Armed Color (Solid) | OFF |
| Button Diameter (mm) | 40 |
| Connection | Integral QD |
| Contact Quantity | 2 NC, 1 NO |
| Contact Rating | 2 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 103 x 110 x 81 |
| Illumination Type | Button |
| In-Series Diagnostics | No |
| Max Operating Temperature (C) | 55 |
| Min Operating Temperature (C) | -25 |
| Mounting Thread/Style | Flat |
| Actuation | Twist/Pull-to-Release |
| Device type | Push Button |
| EPLAN Original Sent Date | 10/27/2022 |
| EPLAN Status | Published |
| Feature | Illuminated, Quick Disconnect |
| Housing Style | Base |
| Item Status | RELEASED |
| Operating voltage | 21.6-26.4 V ac/dc |
| Port | M12 |
| Protection class shaft | IP65 |
| Receptacle housing material A | Thermoplastic |
| Receptacle housing material B | Polycarbonate |
| Voltage supply connection | M12 |
Description
SSA-EB1 Flush-mount Emergency Stop Push Button
Illuminated (PUSH ON) 40 mm Actuator
IP65; Contacts: 2NC/1 NO; 8-pin M12 QD
