Panel Mount Emergency Stop Button – Banner – SSA-EBM-02L
22 mm Metal E-Stop Button Kit
Kit Includes: 40 mm Actuator on Metal Shaft
Metal Mounting Adapter, 2 NC Contacts
E-Stop Legend
| Button Diameter (mm) | 40 |
|---|---|
| Contact Quantity | 2 NC |
| Contact Rating | 2 A @ 30 V dc |
| Dimensions (HxWxD mm ) | 93 x 40 |
| Max Operating Temperature (C) | 60 |
| Min Operating Temperature (C) | -25 |
| Mounting Thread/Style | 22 mm |
| Actuation | Twist-to-Release |
| Device type | Push Button |
| EPLAN Original Sent Date | 10/18/2024 |
| EPLAN Status | Published |
| Housing Style | Base |
| Item Status | RELEASED |
| Protection class shaft | IP65 |
| Receptacle housing material A | Thermoplastic |
| Receptacle housing material B | Polycarbonate |
| Voltage supply connection | Screw Terminal |
Description
22 mm Metal E-Stop Button Kit
Kit Includes: 40 mm Actuator on Metal Shaft
Metal Mounting Adapter, 2 NC Contacts
E-Stop Legend
