Radio Transmission System DX80N2Q45TH
Radio Transmission System
| Ambient temperature max. (°C) | 70 |
|---|---|
| Ambient temperature min. (°C) | -40 |
| Antenna connection | Internal (wire loop) |
| Communication protocol | 1-wire-serial |
| Connector type | M12 × 1 |
| Design | Rectangular |
| Dimensions | 68.9 mm x 44.5 mm x 110.6 mm |
| Electrical output | Connector |
| Frequency band | 2.4-GHz ISM band |
| Frequency range | 2.402…2.483 GHz |
| Function | Temperature sensor |
| Housing material | Plastic |
| Housing quality | Lexan, PBT |
| Input type | Temperature/humidity |
| Max. range (mm) | 1000000 |
| Operating voltage | DC |
| Output type | 2-color LED indicator (red/green) |
| Protection class | IP67 |
| Runs with battery | Yes |
| Special features | wireless |
