BA3201 Pageant CPU Module – BA3201
Features:
Ex ia intrinsic safety certification
Certification allows module to be plugged into a Pageant BA3101 Ex ia intrinsically safe Operator Display.
Module contains:
Power connectionCentral ProcessorCODESYS® runtime software and application codeIEC 61131-3 compliant PLCVisualization engine
Programming port enables CODESYS application code to be downloaded in a safe area.
| Approvals | ATEX, IECEx, UKEX |
|---|---|
| Protection class | IP20 |
| Brand | Beka |
| Mounting | Plug-in |
Product details
All Pageant BA3101 intrinsically safe Operator Displays require a plug-in CPU module fitting in the display socket ‘C’. Alterative CPU Modules can be selected to provide the required external communication.
The BA3201 Pageant BA3201 CPU module contains the BA3101 Operator Display’s central processing unit (CPU) and associated memory but provides no external communication. CODESYS® runtime software is resident including an IEC61131-3 compliant PLC and visualization engine enabling screens designed in the CODESYS integrated development environment (IDE) to be displayed on the BA3101 Operator Display.
A programming port on the rear of the module enables CODESYS application code to be downloaded to the CPU module in a safe area. Connection to a PC USB is made via a BEKA BA3902 Pageant Programming Cable.
A two part connector provides power from the BEKA power isolator.
