ASi Cordsets 7/8"

Standard Cordsets in Yellow (Type 254), Black (Type 254BK) and (Blue Type 254B)

7/8" Cordsets, Connector on One End Only

ASi Cable Type 254





RKM Female Straight       WKM Female Right-Angled     RSM Male Straight WSM         Male Right-Angled

Connector Dimensions in Inches (millimetres)

Meaning of Type Codes


Type Size Gender Connector Style ST=Straight  RA=Right-Angled Cable Length Design
RKM254-1M 7/8" Female ST 1
RKM254-2M 7/8" Female ST 2
RKM254-4M 7/8" Female ST 4
RKM254-6M 7/8" Female ST 6
RKM254-8M 7/8" Female ST 8
RKM254-10M 7/8" Female ST 10
RKM254-15M 7/8" Female ST 15
WKM254-1M 7/8" Female RA 1
WKM254-2M 7/8" Female RA 2
WKM254-4M 7/8" Female RA 4
WKM254-6M 7/8" Female RA 6
WKM254-8M 7/8" Female RA 8
WKM254-10M 7/8" Female RA 10
WKM254-15M 7/8" Female RA 15
RSM254-1M 7/8" Male ST 1
RSM254-2M 7/8" Male ST 2
RSM254-4M 7/8" Male ST 4
RSM254-6M 7/8" Male ST 6
RSM254-8M 7/8" Male ST 8
RSM254-10M 7/8" Male ST 10
RSM254-15M 7/8" Male ST 15
WSM254-1M 7/8" Male ST 1
WSM254-2M 7/8" Male RA 2
WSM254-4M 7/8" Male RA 4
WSM254-6M 7/8" Male RA 6
WSM254-8M 7/8" Male RA 8
WSM254-10M 7/8" Male RA 10
WSM254-15M 7/8" Male RA 15







7/8" Cordsets, Connector on One End Only

ASi Cable Type 254BK





RKM Female Straight       WKM Female Right-Angled     RSM Male Straight WSM         Male Right-Angled

Connector Dimensions in Inches (millimetres)


Type Size Gender Connector Style ST=Straight  RA=Right-Angled Cable Length Design
RKM254BK-1M 7/8" Female ST 1
RKM254BK-2M 7/8" Female ST 2
RKM254BK-4M 7/8" Female ST 4
RKM254BK-6M 7/8" Female ST 6
RKM254BK-8M 7/8" Female ST 8
RKM254BK-10M 7/8" Female ST 10
RKM254BK-15M 7/8" Female ST 15
WKM254BK-1M 7/8" Female RA 1
WKM254BK-2M 7/8" Female RA 2
WKM254BK-4M 7/8" Female RA 4
WKM254BK-6M 7/8" Female RA 6
WKM254BK-8M 7/8" Female RA 8
WKM254BK-10M 7/8" Female RA 10
WKM254BK-15M 7/8" Female RA 15
RSM254BK-1M 7/8" Male ST 1
RSM254BK-2M 7/8" Male ST 2
RSM254BK-4M 7/8" Male ST 4
RSM254BK-6M 7/8" Male ST 6
RSM254BK-8M 7/8" Male ST 8
RSM254BK-10M 7/8" Male ST 10
RSM254BK-15M 7/8" Male ST 15
WSM254BK-1M 7/8" Male ST 1
WSM254BK-2M 7/8" Male RA 2
WSM254BK-4M 7/8" Male RA 4
WSM254BK-6M 7/8" Male RA 6
WSM254BK-8M 7/8" Male RA 8
WSM254BK-10M 7/8" Male RA 10
WSM254BK-15M 7/8" Male RA 15







7/8" Cordsets, Connector on One End Only

ASi Cable Type 254B





RKM Female Straight       WKM Female Right-Angled     RSM Male Straight WSM         Male Right-Angled

Connector Dimensions in Inches (millimetres)


Type Size Gender Connector Style ST=Straight  RA=Right-Angled Cable Length Design
RKM254B-1M 7/8" Female ST 1
RKM254B-2M 7/8" Female ST 2
RKM254B-4M 7/8" Female ST 4
RKM254B-6M 7/8" Female ST 6
RKM254B-8M 7/8" Female ST 8
RKM254B-10M 7/8" Female ST 10
RKM254B-15M 7/8" Female ST 15
WKM254B-1M 7/8" Female RA 1
WKM254B-2M 7/8" Female RA 2
WKM254B-4M 7/8" Female RA 4
WKM254B-6M 7/8" Female RA 6
WKM254B-8M 7/8" Female RA 8
WKM254B-10M 7/8" Female RA 10
WKM254B-15M 7/8" Female RA 15
RSM254B-1M 7/8" Male ST 1
RSM254B-2M 7/8" Male ST 2
RSM254B-4M 7/8" Male ST 4
RSM254B-6M 7/8" Male ST 6
RSM254B-8M 7/8" Male ST 8
RSM254B-10M 7/8" Male ST 10
RSM254B-15M 7/8" Male ST 15
WSM254B-1M 7/8" Male ST 1
WSM254B-2M 7/8" Male RA 2
WSM254B-4M 7/8" Male RA 4
WSM254B-6M 7/8" Male RA 6
WSM254B-8M 7/8" Male RA 8
WSM254B-10M 7/8" Male RA 10
WSM254B-15M 7/8" Male RA 15
