Standard Cordsets in Yellow (Type 254), Black (Type 254BK) and (Blue Type 254B)

7/8" Cordsets, Connector on Both Ends



RKM Female Straight       WKM Female Right-Angled     RSM Male Straight WSM         Male Right-Angled

Connector Dimensions in Inches (millimetres)

Meaning of Type Codes











Cordset Type for Cable Type 254 (Yellow) Cordset Type for Cable Type 254BK (Black) Cordset Type for Cable Type 254B (Blue) Connector Style St=Straight   RA=Right-Angled Cable Length
RSM RKM 254-1M RSM RKM 254BK-1M RSM RKM 254B-1M Male St-Female St 1
RSM RKM 254-2M RSM RKM 254BK-2M RSM RKM 254B-2M Male St-Female St 2
RSM RKM 254-4M RSM RKM 254BK-4M RSM RKM 254B-4M Male St-Female St 4
RSM RKM 254-6M RSM RKM 254BK-6M RSM RKM 254B-6M Male St-Female St 6
RSM RKM 254-8M RSM RKM 254BK-8M RSM RKM 254B-8M Male St-Female St 8
RSM RKM 254-10M RSM RKM 254BK-10M RSM RKM 254B-10M Male St-Female St 10
RSM RKM 254-15M RSM RKM 254BK-15M RSM RKM 254B-15M Male St-Female St 15
RSM RSM 254-1M RSM RSM 254BK-1M RSM RSM 254B-1M Male St-Male ST 1
RSM RSM 254-2M RSM RSM 254BK-2M RSM RSM 254B-2M Male St-Male ST 2
RSM RSM 254-4M RSM RSM 254BK-4M RSM RSM 254B-4M Male St-Male ST 4
RSM RSM 254-6M RSM RSM 254BK-6M RSM RSM 254B-6M Male St-Male ST 6
RSM RSM 254-8M RSM RSM 254BK-8M RSM RSM 254B-8M Male St-Male ST 8
RSM RSM 254-10M RSM RSM 254BK-10M RSM RSM 254B-10M Male St-Male ST 10
RSM RSM 254-15M RSM RSM 254BK-15M RSM RSM 254B-15M Male St-Male ST 15
RKM RKM 254-1M RKM RKM 254BK-1M RKM RKM 254B-1M Female ST-Female St 1
RKM RKM 254-2M RKM RKM 254BK-2M RKM RKM 254B-2M Female ST-Female ST 2
RKM RKM 254-4M RKM RKM 254BK-4M RKM RKM 254B-4M Female ST-Female ST 4
RKM RKM 254-6M RKM RKM 254BK-6M RKM RKM 254B-6M Female ST-Female ST 6
RKM RKM 254-8M RKM RKM 254BK-8M RKM RKM 254B-8M Female ST-Female ST 8
RKM RKM 254-10M RKM RKM 254BK-10M RKM RKM 254B-10M Female ST-Female ST 10
RKM RKM 254-15M RKM RKM 254BK-15M RKM RKM 254B-15M Female ST-Female ST 15
WSM WKM 254-1M WSM WKM 254BK-1M WSM WKM 254B-1M Male RA-Female RA 1
WSM WKM 254-2M WSM WKM 254BK-2M WSM WKM 254B-2M Male RA-Female RA 2
WSM WKM 254-4M WSM WKM 254BK-4M WSM WKM 254B-4M Male RA-Female RA 4
WSM WKM 254-6M WSM WKM 254BK-6M WSM WKM 254B-6M Male RA-Female RA 6
WSM WKM 254-8M WSM WKM 254BK-8M WSM WKM 254B-8M Male RA-Female RA 8
WSM WKM 254-10M WSM WKM 254BK-10M WSM WKM 254B-10M Male RA-Female RA 10
WSM WKM 254-15M WSM WKM 254BK-15M WSM WKM 254B-15M Male RA-Female RA 15
WSM WSM 254-1M WSM WSM 254BK-1M WSM WSM 254B-1M Male RA-Male RA 1
WSM WSM 254-2M WSM WSM 254BK-2M WSM WSM 254B-2M Male RA-Male RA 2
WSM WSM 254-4M WSM WSM 254BK-4M WSM WSM 254B-4M Male RA-Male RA 4
WSM WSM 254-6M WSM WSM 254BK-6M WSM WSM 254B-6M Male RA-Male RA 6
WSM WSM 254-8M WSM WSM 254BK-8M WSM WSM 254B-8M Male RA-Male RA 8
WSM WSM 254-10M WSM WSM 254BK-10M WSM WSM 254B-10M Male RA-Male RA 10
WSM WSM 254-15M WSM WSM 254BK-15M WSM WSM 254B-15M Male RA-Male RA 15
WKM WKM 254-1M WKM WKM 254BK-1M WKM WKM 254B-1M Female RA-Female RA 1
WKM WKM 254-2M WKM WKM 254BK-2M WKM WKM 254B-2M Female RA-Female RA 2
WKM WKM 254-4M WKM WKM 254BK-4M WKM WKM 254B-4M Female RA-Female RA 4
WKM WKM 254-6M WKM WKM 254BK-6M WKM WKM 254B-6M Female RA-Female RA 6
WKM WKM 254-8M WKM WKM 254BK-8M WKM WKM 254B-8M Female RA-Female RA 8
WKM WKM 254-10M WKM WKM 254BK-10M WKM WKM 254B-10M Female RA-Female RA 10
WKM WKM 254-15M WKM WKM 254BK-15M WKM WKM 254B-15M Female RA-Female RA 15
RSM WSM 254-1M RSM WSM 254BK-1M RSM WSM 254B-1M Male St-Male RA 1
RSM WSM 254-2M RSM WSM 254BK-2M RSM WSM 254B-2M Male St-Male RA 2
RSM WSM 254-4M RSM WSM 254BK-4M RSM WSM 254B-4M Male St-Male RA 4
RSM WSM 254-6M RSM WSM 254BK-6M RSM WSM 254B-6M Male St-Male RA 6
RSM WSM 254-8M RSM WSM 254BK-8M RSM WSM 254B-8M Male St-Male RA 8
RSM WSM 254-10M RSM WSM 254BK-10M RSM WSM 254B-10M Male St-Male RA 10
RSM WSM 254-15M RSM WSM 254BK-15M RSM WSM 254B-15M Male St-Male RA 15
RSM WKM 254-1M RSM WKM 254BK-1M RSM WKM 254B-1M Male St-Female RA 1
RSM WKM 254-2M RSM WKM 254BK-2M RSM WKM 254B-2M Male St-Female RA 2
RSM WKM 254-4M RSM WKM 254BK-4M RSM WKM 254B-4M Male St-Female RA 4
RSM WKM 254-6M RSM WKM 254BK-6M RSM WKM 254B-6M Male St-Female RA 6
RSM WKM 254-8M RSM WKM 254BK-8M RSM WKM 254B-8M Male St-Female RA 8
RSM WKM 254-10M RSM WKM 254BK-10M RSM WKM 254B-10M Male St-Female RA 10
RSM WKM 254-15M RSM WKM 254BK-15M RSM WKM 254B-15M Male St-Female RA 15
WSM RKM 254-1M WSM RKM 254BK-1M WSM RKM 254B-1M Male RA-Female St 1
WSM RKM 254-2M WSM RKM 254BK-2M WSM RKM 254B-2M Male RA-Female St 2
WSM RKM 254-4M WSM RKM 254BK-4M WSM RKM 254B-4M Male RA-Female St 4
WSM RKM 254-6M WSM RKM 254BK-6M WSM RKM 254B-6M Male RA-Female St 6
WSM RKM 254-8M WSM RKM 254BK-8M WSM RKM 254B-8M Male RA-Female St 8
WSM RKM 254-10M WSM RKM 254BK-10M WSM RKM 254B-10M Male RA-Female St 10
WSM RKM 254-15M WSM RKM 254BK-15M WSM RKM 254B-15M Male RA-Female St 15
RKM WKM 254-1M RKM WKM 254BK-1M RKM WKM 254B-1M Female ST-Female RA 1
RKM WKM 254-2M RKM WKM 254BK-2M RKM WKM 254B-2M Female ST-Female RA 2
RKM WKM 254-4M RKM WKM 254BK-4M RKM WKM 254B-4M Female ST-Female RA 4
RKM WKM 254-6M RKM WKM 254BK-6M RKM WKM 254B-6M Female ST-Female RA 6
RKM WKM 254-8M RKM WKM 254BK-8M RKM WKM 254B-8M Female ST-Female RA 8
RKM WKM 254-10M RKM WKM 254BK-10M RKM WKM 254B-10M Female ST-Female RA 10
RKM WKM 254-15M RKM WKM 254BK-15M RKM WKM 254B-15M Female ST-Female RA 15
